| Hoisng: | plastic housing for wall mounting |
| Dimensions: | 184 x 223 x 82mm (w x h x d) |
| Safety Type: | IP 65 according to German DIN 40050 |
| Measurement range: |
10 mS/cm = 20 mA 20 mS/cm = 20 mA 100 mS/cm = 20 mA 200 mS/cm = 20 mA (ex-works settings) |
| Conductivity indication: | digital, LC-Display |
| Temperature indication: | digital, LC-Display |
| Temperature compensation: |
10-100°C, automatically with temperature sensor NTC 2 possible temperature compensation factors: acid (1.25%/K) and caustic (1.9%/K) (ex-works settings) |
| Pre-metering: | 0-9999 s. adjustable in steps of 1 s |
| Pre-metering time delay: | 0-9999 s. adjustable in steps of 1 s |
| Metering time limitation: | 10-9999 s. adjustable in steps of 1 s |
| Switch outputs: |
1 floating change-over contact for SP 1, load capacity 8 A/230 V AC 1 floating change-over contact for SP 2, load capacity 4 A/230 V AC 1 floating change-over contact for fault message signal, load capacity 4 A/230 V AC 1 floating change-over contact for pre-metering (additionally configurable). load capacity 4 A/230 V AC |
| Current output: | 0/4-20 mA corresponding to 0-100 % of the set measuring range max. electric burden resistor 400 |
| Inputs: |
1 floating make contact for pre-metering start 1 floating break contact for metering lock 1 empty signal input for empty signal monitoring by means of reed contact |
| Mains power supply: |
230 V - 240 V AC 115 V - 120 V AC 24 V AC |
| Mains frequency: | 50 Hz - 60 Hz |
| Ambient temperature: | 0° C-max. 50° C for the wall mount housing |
| Weight: | approx. 3 kg |
